Electronics lab

July 25, 2016 | 5:00 pm

The electronics lab is located in room 210C and contains soldering irons, oscilloscopes, multi-meters, and more.

Soldering irons

QK4A4000-adjusted

PCB shear

QK4A4002-adjusted

Oscilloscopes and power supplies

QK4A4005-adjusted

Multi-meters

QK4A4010-adjusted

Saleae logic analyzer

QK4A4025-adjusted

Heat guns

QK4A4014-adjusted

Stereo Microscope

QK4A4016-adjusted

Function Generators

QK4A4021-adjusted

Fume extractors

QK4A4032-adjusted

VirtualBench

QK4A4026-adjusted
